Altitude Encoder Compatibility

 Post Reply Post Reply
Author
Message
PredFan View Drop Down
Newbie
Newbie


Joined: 03 Jun 2017
Location: Knoxville, TN
Status: Offline
Points: 8
Post Options Post Options   Thanks (0) Thanks(0)   Quote PredFan Quote  Post ReplyReply Direct Link To This Post Topic: Altitude Encoder Compatibility
    Posted: 27 Aug 2017 at 4:59pm
I'm getting ready to wire my AXP340 per the installation manual. My existing encoder is a Trans-Cal D120-P2-T. Should I expect issues that might require updating my encoder? I have already replaced a Garmin 430W with an IFD440.
Back to Top
LANCE View Drop Down
Senior Member
Senior Member


Joined: 06 Dec 2014
Location: TEXAS
Status: Offline
Points: 216
Post Options Post Options   Thanks (0) Thanks(0)   Quote LANCE Quote  Post ReplyReply Direct Link To This Post Posted: 28 Aug 2017 at 7:59am
Most installers I've talked to recommend the Trans-Cal Nano (http://www.aircraftspruce.com/catalog/avpages/transcalencoder.php)
For $269 it sounds like it would be worth it and it looks like it is pin compatible with yours current encoder.


Edited by LANCE - 28 Aug 2017 at 8:03am
Back to Top
PredFan View Drop Down
Newbie
Newbie


Joined: 03 Jun 2017
Location: Knoxville, TN
Status: Offline
Points: 8
Post Options Post Options   Thanks (0) Thanks(0)   Quote PredFan Quote  Post ReplyReply Direct Link To This Post Posted: 28 Aug 2017 at 1:09pm
Thanks Lance, I've got a call into Tech support to get their thoughts as well.
Back to Top
rsharp View Drop Down
Newbie
Newbie
Avatar

Joined: 11 Jan 2018
Location: CA
Status: Offline
Points: 9
Post Options Post Options   Thanks (0) Thanks(0)   Quote rsharp Quote  Post ReplyReply Direct Link To This Post Posted: 16 Jan 2018 at 8:16pm
Another acceptable Serial Encoder is the ACK A30.9 (Mod 9) encoder. ($245)
Its suppose to work with the AXP340, SkyTrax100 and the IDF5x0 series.
You have 2ea serial RS232 lines, split one line off to connect to the 2 units.
I just ordered the unit and waiting for my avionics.
Randy

Regards,
Back to Top
chflyer View Drop Down
Senior Member
Senior Member
Avatar

Joined: 24 Jan 2013
Location: LSZK
Status: Offline
Points: 551
Post Options Post Options   Thanks (0) Thanks(0)   Quote chflyer Quote  Post ReplyReply Direct Link To This Post Posted: 17 Jan 2018 at 4:35am
If we're listing encoders that work with the AXP340, I have a Sandia 5-35 that was installed before my AXP340. It also has 2x serial output. Sandia is high quality and works well together with my AXP340 and IFDs.
Vince
Back to Top
rsharp View Drop Down
Newbie
Newbie
Avatar

Joined: 11 Jan 2018
Location: CA
Status: Offline
Points: 9
Post Options Post Options   Thanks (0) Thanks(0)   Quote rsharp Quote  Post ReplyReply Direct Link To This Post Posted: 17 Jan 2018 at 2:18pm
Yes Sandia is a great company with some great products.
Wish I had it in the budget to get the Sandia SAC 7-35 Air Data Computer.
It's around $2750 but the box has 4 functions: ADC, Encoder, FF monitor, and Altitude alerter.
This ADC I believe would put A/S & Altitude strips on the 550 while viewing in the SVS mode.
Randy

Regards,
Back to Top
